Eagle 10 HP 120 Gal Two-Stage Piston Air Compressor
Models
101120H2-MS208 | 103120H2-MS208 | 103120H2-MS230 | 103120H2-CS460 | 105120H2-CS575
Eagle 10 HP Two-Stage Piston Air Compressor (120-Gal Horizontal, 3-Phase)
Step up to elite-level pneumatic performance with the Eagle 10 HP Two-Stage Horizontal Piston Air Compressor. Engineered for demanding industrial environments, this compressor is the ultimate solution for facilities that require high-pressure, high-volume air day in and day out.
By combining the proven efficiency of a 10 HP 3-phase motor with a heavy-duty two-stage pump and a massive 120-gallon horizontal receiver, this unit is built to tackle your shop’s most aggressive duty cycles while maintaining consistent, reliable line pressure.
Key Specifications & Features
- Two-Stage Cast Iron Pump: Unlike single-stage pumps, this two-stage system compresses the air twice, easily generating maximum pressures up to 175 PSI. This design features a finned intercooler that lowers air temperature between stages, significantly increasing efficiency and extending the life of the pump.
- 10 HP Industrial Motor (3-Phase): Designed for heavy commercial power grids, this 3-phase motor runs exceptionally smooth and cool. It provides the brute force needed to drive the two-stage pump while drawing lower amperage per leg than single-phase alternatives, saving you money on long-term electrical costs.
- 120-Gallon Horizontal Air Receiver: The massive ASME-certified 120-gallon tank acts as a colossal pneumatic battery. It prevents the pump from short-cycling during heavy tool usage. The horizontal orientation provides a highly stable, low center of gravity and is ideal for shops with vertical height restrictions or low ceilings.
- Exceptional CFM Output: Delivers massive air volume (Cubic Feet per Minute) at high pressures, ensuring your crew never experiences a drop in performance when running multiple continuous-use tools simultaneously.
- Industrial-Grade Components: Outfitted with heavy-duty commercial pressure switches, high-efficiency reed valves, oversized bearings, and a rugged, fully enclosed metal belt guard for maximum workplace safety.
Ideal Applications
This 10 HP two-stage workhorse is designed for heavy industry and shops that push their equipment to the limit:
- Commercial auto body shops running continuous DA sanders and high-volume paint booths
- Heavy metal fabrication, plasma cutting, and multi-station welding shops
- Industrial sandblasting, powder coating, and surface preparation facilities
- Large-scale fleet maintenance and commercial truck tire centers (running 1-inch impact wrenches)
- Manufacturing facilities requiring steady, high-pressure (175 PSI) air for pneumatic automation
| Model | Gal | Hp | CFM | Tank | Max PSI | Voltage | Weight | Dimensions L x W X H (in) |
|---|---|---|---|---|---|---|---|---|
| 101120H2-MS208 | 120 | 10 | 36 | Steel | 200 | 208V / 1 Phase | 741 | 72 x 27 x 50 |
| 103120H2-MS208 | 120 | 10 | 36 | Steel | 200 | 208V / 3 Phase | 722 | 72 x 27 x 50 |
| 103120H2-MS230 | 120 | 10 | 36 | Steel | 200 | 230V / 3 Phase | 722 | 72 x 27 x 50 |
| 103120H2-CS460 | 120 | 10 | 36 | Steel | 200 | 460V / 3 Phase | 722 | 72 x 27 x 50 |
| 105120H2-CS575 | 120 | 10 | 36 | Steel | 200 | 575V / 3 Phase | 722 | 72 x 27 x 50 |
|
Manufacture’s Warranty |
1 year limited warranty |
|---|
