Iron Horse 7.5 HP Stationary Compressors 80-Gallon: Industrial Air Power for Any Facility
When your business relies on continuous, high-volume air, you cannot afford downtime. Designed for professional auto body shops, agricultural facilities, manufacturing floors, and heavy-duty commercial garages, the Iron Horse 7.5 HP 80-Gallon Stationary Compressors deliver the uncompromising power you need.
These massive, vertical powerhouses are built around a rugged, three-cylinder cast-iron pump featuring a highly efficient “V” design. This design minimizes vibration, significantly improves cooling, and extends the overall life of the machine. Generating a massive 22 CFM at 90 PSI (and capable of up to 175 PSI maximum working pressure), these compressors easily handle continuous use of DA sanders, heavy impact wrenches, plasma cutters, and multi-bay operations.
Shared Professional-Grade Features
No matter which electrical configuration your facility requires, every model in this lineup is built to the exact same heavy-duty standard:
- V-Style Cast Iron Pump: Features three individual, removable cylinders. The larger bore pistons run at lower RPMs, reducing friction and heat while outproducing the competition.
- Massive 80-Gallon ASME Tank: Government-certified, vertical tank saves premium floor space while storing enough air to ensure longer run times between motor cycles.
- Built-in Aftercooler: Premium heat removal system delivers cooler, denser air to your lines, improving tool life and reducing moisture build-up.
- Easy Maintenance: Equipped with an easy-view oil sight gauge so you can check lubrication levels at a single glance.
- Safety First: Features a fully enclosed, sturdy metal belt guard that protects both the drive system and the operator, meeting or exceeding OSHA safety standards.
Choose Your Electrical Configuration
The core performance of these machines is identical; your choice depends entirely on your shop’s electrical supply. Iron Horse offers configurations ranging from single-phase (perfect for smaller shops or serious residential garages) up to 575V 3-phase for heavy industrial manufacturing floors.
| Model Number | Phase / Voltage | Starter Type | Approx. Amp Draw | Best Fit For |
| IHD7180V2-MS | 1-Phase (208/230V) | Magnetic Starter | 33 Amps | Shops or serious home garages without 3-phase access. |
| IHD7380V2-CS2 | 3-Phase (208/230V) | Combo Switch | 23 Amps | Commercial auto shops and mid-sized businesses. |
| IHD7380V2-CS4 | 3-Phase (460V) | Combo Switch | 12 Amps | Industrial facilities running high-voltage commercial lines. |
| IHD7580V2-CS | 3-Phase (575V) | Combo Switch | 9 Amps | Heavy manufacturing and specialized industrial plants. |
Pro Tip: The 3-phase models (CS2, CS4, and CS) utilize an advanced Combo Switch that improves performance and reduces the overall footprint by eliminating the need for a traditional magnetic starter.
The Backbone of Your Business
Iron Horse stands behind their engineering. These stationary units are assembled right here in the USA, ensuring rigorous quality control and delivering a compressor that is ready to power your daily operations for years to come.
