Mi-T-M AM1 Portable Series

Mi-T-M AM1 Portable Series

The Mi-T-M AM1 Portable Series Compressors are engineered for the professional contractor who needs a large air reserve and industrial-grade durability in a mobile package. These 20-gallon units are designed to serve as the primary air source on a jobsite, providing the sustained pressure and volume required for high-production framing, roofing, and flooring crews.

Model AM1-PE15-20M

The High-Efficiency Workhorse

The AM1-PE15-20M is optimized for maximum performance on a standard 120V circuit. It utilizes a high-quality 1.5 HP electric motor paired with a heavy-duty pump to deliver consistent air without constantly tripping breakers on older jobsites.

• Motor: 1.5 HP, 120V, 13.2 amp electric motor with thermal overload protection.
• Performance: 4.2 CFM @ 90 PSI.
• Pump: Splash-lubricated cast iron crankcase and cylinder for long-term industrial reliability.
• Tank: 20-gallon horizontal tank with a powder-coated finish for superior corrosion resistance.
• Key Feature: Features a high-quality regulator and dual gauges for precise tool adjustment and tank pressure monitoring.
• Best For: Professional finish work, cabinetry, and general remodeling where a large air reserve is needed to minimize motor cycling.

Model AM1-PE02-20M

The High-Output Professional

When your job demands faster recovery times and higher air volume, the AM1-PE02-20M delivers. Featuring a more powerful 2.0 HP motor, this unit is built to keep up with rapid-fire pneumatic tools and multi-tool manifolds.

• Motor: 2.0 HP, 120V, 18.8 amp electric motor.
• Performance: 4.2 CFM @ 90 PSI with a focus on faster tank recovery.
• Pump: Heavy-duty, single-stage cast iron pump designed for high-duty cycles.
• Components: Equipped with a stainless-steel braided discharge hose and a large-diameter intake filter for improved airflow and protection.
• Tank: 20-gallon horizontal configuration mounted on a rugged wheeled frame.
• Best For: Framing crews, sub-flooring, and roofing where the tools are demanding and the work pace is fast.

Shared Professional Features

• Superior Mobility: Both models feature a “stroller” style handle and oversized semi-pneumatic tires, making it easy to maneuver the 20-gallon tank over jobsite debris and through narrow doorways.
• Cast Iron Durability: Unlike consumer-grade “oil-less” units, these cast iron pumps are built to be rebuilt, ensuring years of service in harsh environments.
• Advanced Protection: The motors are shielded from debris, and the critical components are protected by the rugged frame design.
• Vibration Reduction: Industrial rubber isolators under the motor and pump reduce vibration and prevent the unit from “walking” during operation.

Quick Comparison
