Mi-T-M Hand Carry Compressors

Mi-T-M Hand Carry Compressors

The Mi-T-M Hand Carry Compressors Series is engineered for contractors and high-end DIYers who require industrial-grade durability in a format that can be easily tossed into a truck bed or carried across a jobsite. From ultra-quiet electric units to high-performance gas models, these compressors are built with professional-grade components like stainless-steel braided hoses and cast-iron cylinders.

Model AM1-HE15-03QM (Work Pro Series)

The Quiet Electric Specialist

Part of the Work Pro® Series, the AM1-HE15-03QM is designed for indoor environments where noise reduction is critical. It delivers impressive air power while maintaining an operating level of less than 70 dBA, making it ideal for finish carpentry and occupied remodels.

• Performance: 4.2 CFM @ 90 PSI.
• Motor: 1.5 HP, 120V Electric Induction Motor.
• Tank: 3-Gallon single tank with a protective powder-coated finish.
• Key Feature: Features an integrated control panel with a regulator and dual gauges for precise air management.
• Best For: Trim work, indoor renovations, and powering small impact wrenches or grinders without the industrial roar.

Model AM1-HE02-05M

The High-Capacity Electric Twin-Tank

When you need more air storage and a true 100% duty cycle pump, the AM1-HE02-05M steps up. This unit utilizes a heavy-duty cast-iron cylinder and a larger air reserve to handle more demanding, continuous pneumatic tasks.

• Performance: 4.2 CFM @ 90 PSI.
• Motor: 2.0 HP, 120V Electric Motor.
• Tank: 5-Gallon “Twin Tank” configuration for maximum air storage and stability.
• Construction: Splash-lubricated aluminum crankcase with a cast-iron cylinder for superior heat dissipation.
• Best For: Framing, roofing, and general construction where electrical power is available but a higher volume of air is required.

Model AM1-HH04-05M (Honda Powered)

The Jobsite Gold Standard

For remote jobsites where power poles aren’t yet installed, this unit pairs a professional Mi-T-M pump with the legendary reliability of a Honda GX120 engine. It is a favorite for framing and roofing crews who demand consistent performance in all weather conditions.

• Engine: 118cc Honda GX120 OHV with recoil start.
• Performance: 4.8 CFM @ 90 PSI.
• Tank: 5-Gallon Twin-Tank assembly protected by a wrap-around roll cage frame.
• Engine Control: Features a pneumatic engine idle control to conserve fuel and reduce noise when air demand is low.
• Best For: Professional framing, remote construction, and agricultural maintenance.

Model AM1-HM04-05M (Mi-T-M Gas Powered)

The Versatile Gas Workhorse

The AM1-HM04-05M offers the same high-output pneumatic performance as its Honda-powered sibling but utilizes a high-displacement Mi-T-M OHV engine. It provides a rugged, independent power source for users who need maximum CFM for their dollar.

• Engine: 212cc Mi-T-M OHV Engine (featuring low-oil shutdown).
• Performance: 4.8 CFM @ 90 PSI.
• Tank: 5-Gallon Twin-Tank with heavy-duty rubber isolators to minimize vibration.
• Durability: Equipped with a stainless-steel braided discharge hose and a canister-style inlet air filter.
• Best For: Residential construction, large property maintenance, and DIYers who need gas-powered portability for remote tasks.

Quick Specification Comparison
