Nano TMC Cycling Refrigerated Dryers

Price range: $2,250.00 through $13,125.00

Dryer CFM

Clear

SKU: N/A Category: Cycling

Nano TMC Cycling Refrigerated Dryers

Thermal Mass Cycling Refrigerated Dryers

Are you tired of high energy bills from traditional dryers? Introducing the TMC thermal mass cycling refrigerated compressed air dryer with a unique glycol thermal mass that can save you up to 80% on power! This innovative dryer matches power to actual demand and conditions, guaranteeing a steady dew point performance, low-pressure drop, and reliable operation. Say goodbye to the hassle of continuous maintenance and enjoy worry-free, clean, and dry compressed air. Plus, you may be eligible for rebates in many parts of the country due to its energy-saving capabilities. Upgrade to the TMC thermal mass cycling dryer today for a more efficient and cost-effective compressed air solution!

The system features a revolutionary Thermal Mass Circuit (TMC) that uses a unique glycol thermal mass to save energy and money. This technology treats the compressed air based on the actual flow, delivering a constant flow of cold liquid to ensure a consistent dew point in the compressed air outlet.

Thermal Mass Refrigerated Dryer Model	Recommended Filtration		Inlet & Outlet	Rated Flow at 100 psig	Absorbed Power	Power Supply (V/Ph/60Hz)
Thermal Mass Refrigerated Dryer Model	Prefilter	After Filter	NPT	scfm	kW	115/1	230/1	460/3
TMC 0030 N	GFN 0050 M1	GFN 0050 M01	½”	30	0.44	•
TMC 0055 N	GFN 0085 M1	GFN 0085 M01	½”	55	0.78	•
TMC 0075 N	GFN 0105 M1	GFN 0085 M01	1 ¼”	75	0.83	•
TMC 0105 N	GFN 0105 M1	GFN 0105 M01	1 ¼”	105	1.1	•
TMC 0130 N	GFN 0105 M1	GFN 0105 M01	1 ½”	130	1.0	•
TMC 0170 N	GFN 0125 M1	GFN 0125 M01	1 ½”	170	1.1	•
TMC 0200 N	GFN 0325 M1	GFN 0325 M01	1 ½”	200	1.3		•
TMC 0265 N	GFN 0325 M1	GFN 0325 M01	1 ½”	265	1.9		•
TMC 0320 N	GFN 0450 M1	GFN 0450 M01	2″	320	2.5			•
TMC 0400 N	GFN 0450 M1	GFN 0450 M01	2″	400	3.0			•
TMC 0510 N	GFN 0450 M1	GFN 0450 M01	2 ½”	510	3.7			•
TMC 0635 N	GFN 0450 M1	GFN 0450 M01	2 ½”	635	4.7			•

All models make use of environmentally friendly refrigerants R513a and R410a

Weight	82 lbs
Dimensions	17 × 16 × 22 in
Brand	Nano Purification
Connection	1 1/4 in, 1/2 in, 1 1/2 in, 2 1/2 in, 2 in
Dryer CFM	30, 55, 75, 105, 130, 170, 200, 265, 320, 400, 510, 635
Dryer CFM Range	Up to 30
Dryer PSI	232
voltage	115/1/60
