Hankison HPR & HPRN Refrigerated Dryers

Price range: $1,200.00 through $32,500.00

Dryer CFM

voltage

Filtration Option

Clear

SKU: N/A Category: Non Cycling

Hankison HPR & HPRN Refrigerated Dryers

Streamlined HPR & HPRN Series non-cycling refrigerated compressed air dryers, Hankison engineers focused on simplicity and reliability. Your input helped build a solution that offers the right combination of technology and simplicity to keep your air system at a dry, 38°F (+3°C) pressure dew point, from 5 through 1200 scfm. These dryers are built for durability, in a space-saving design. Sturdy sheet steel is formed and protected by an epoxy-based powdercoat finish. Plus, Hankison’s industry leading, five year warranty is now available for the HPRN Series.

MODEL¹	FLOW RATE SCFM²	FLOW RATE M³/H	REFRIGERANT	VOLTAGE	POWER KW	INLET/OUTLET CONNECTIONS
HPR5-10	5	17	R 134a	115/1/60	0.2	3/8″ OD
HPR15	15	25	R 134a	115/1/60	0.24	3/8″ OD
HPR25	25	42	R 134a	115/1/60	0.41	3/4″ NPT
HPR35	35	59	R 134a	115/1/60	0.46	3/4″ NPT
HPR50	50	85	R 134a	115/1/60	0.57	3/4″ NPT
HPRN75	75	127	R 134a	115/1/60	0.52	1″ NPT
HPRN100	100	170	R 134a	115/1/60	0.65	1″ NPT
HPRN125	125	212	R 134a	115/1/60	0.68	1″ NPT
HPRN150-1	150	255	R 407c	115/1/60	0.91	1″ NPT
HPRN200-4	200	340	R 407c	460/3/60	1.81	1″ NPT
HPRN250-4	250	425	R 407c	460/3/60	1.92	2″ NPT
HPRN300-4	300	510	R 407c	460/3/60	2.48	2″ NPT
HPRN400-4	400	680	R 407c	460/3/60	3.09	2″ NPT
HPRN500-4	500	850	R 407c	460/3/60	3.18	2″ NPT
HPRN600³	600	1,020	R 407c	460/3/60	3.8	2″ NPT
HPRN800³	800	1,360	R 407c	460/3/60	5.4	3″ FLG
HPRN1000³	1,000	1,700	R 407c	460/3/60	6.6	4″ FLG
HPRN1200³	1,200	2,040	R 407c	460/3/60	8.7	4″ FLG

¹ 1 = For Filter Pack model, add “-FP” to standard model number. (Example: HPRN75-FP)
Dimensions, weights, and inlet/outlet connections are dryer only and do not include filtration.
Filtration package shipped loose, additional fittings may be required.
² Rated Flow Capacity – Conditions for rating dryers are in accordance with ISO 7183 (Option A2). Compressed air at dryer inlet: 100 psig (6.7 barg) and 100˚F (38˚C); ambient air temperature: 100˚F (38˚C); operating on 60 Hz power supply.
³ Available in water cooled
At rated conditions, pressure drop is less than 5 psig.

FLOW MODEL	MAX INLET AIR PRESSURE		MIN INLET AIR PRESSURE		MAX INLET AIR TEMPERATURE		MIN INLET AIR TEMPERATURE		MAX AMBIENT AIR TEMPERATURE		MIN AMBIENT AIR TEMPERATURE
SCFM	PSIG	BARG	PSIG	BARG	˚F	˚C	˚F	˚C	˚F	˚C	˚F	˚C
5-10 to 50	250	17	30	2	120	49	40	4	110	43	45	7
75 to 500	232	16	43	3	120	49	45	7	110	43	37	3
600-1200	232	16	43	3	120	49	45	7	110	43	34	1

HPR & HPRN Series Refrigerated Air Dryers Improve Productivity, Simple. Reliable.

Weight	270 lbs
Dimensions	19 × 44 × 32 in
Brand	Hankison
Connection	2 in
Dryer CFM	10, 15, 25, 35, 50, 75, 100, 125, 150, 200, 250, 300, 400, 500, 600, 800, 1000, 1200
Dryer CFM Range	275 – 839, 30 – 89, 840 – 2349, 90 – 274, Up to 30
Dryer PSI	232
voltage	115/1/60, 460/3/60, 460/3/60 Water Cooled
Filtration Option	Include, None
