Cost savings
- Low cost per unit of N2 compared to gas cylinders.
- Best-in-class air/energy consumption.
- PSA design adapted for small nitrogen needs.
Easy to install & use
- Easy to hook up to your existing compressed air network.
- Compact footprint takes up little room on your shop floor.
- Advanced controller with remote monitoring.
Reliability
- Stable supply of N2 at a guaranteed purity.
- Designed for continuous duty.
- Self-protective design and future-proof operation.
Meet your exact nitrogen needs
When you just need your N2 and get going, the NGPs has got you covered:
- Proven technology: Extruded aluminum adsorber design ensures a compact footprint, reliable operation and a long lifetime.
- Easy installation and operation: Just connect the NGPs to your compressed air supply and start producing your own N2.
- No wasted air: Avoid the standby losses that nitrogen generators can experience. Through smart valve controls, the NGPs’ Economizer function ensures no air/energy is wasted.
For demanding applications
When your N2 application requires advanced quality, purity and
- Advanced controller:
- 4.3” color touch screen with remote monitoring
- Live machine status and key parameters (N2 purity, pressure, flow, PDP, …)
- Alarms and service information
- User settings, such as Economizer set points, alarms
- Nitrogen check: Measures every unit of N2 before allowing it to reach your application for an absolute purity guarantee.
- Nitrogen PDP sensor: Inspects the quality (moisture level) of the N2 to ensure it matches your specifications.
- Feed air check: Continuously monitors the feed air and, if preferred, blocks it from entering the generator when its quality is below standard.
- Nitrogen flow sensor: Provides an indicative measurement of the live nitrogen capacity at the generator’s outlet.
| Purity | 95% | 96% | 97% | 98% | 99% | 99.50% | 99.90% | 99.95% | 99.99% | 99.995% | 99.999% | Width | Depth | Height | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NGPs 2 | Scfm | 2.5 | 2.3 | 2 | 1.7 | 1.3 | 1 | 0.5 | 17 | 18 | 29 | 119 | ||||
| NGPs 3 | Scfm | 4 | 3.7 | 3.2 | 2.8 | 2.2 | 1.7 | 1 | 0.7 | 0.6 | 0.5 | 0.2 | 17 | 18 | 36 | 139 |
| NGPs 4 | Scfm | 5.6 | 5.1 | 4.6 | 4 | 3.1 | 2.4 | 1.5 | 1.3 | 0.9 | 0.8 | 0.3 | 17 | 18 | 43 | 168 |
| NGPs 5 | Scfm | 6.5 | 5.9 | 5.2 | 4.6 | 3.7 | 3.1 | 1.9 | 1.6 | 1 | 0.8 | 0.5 | 17 | 18 | 49 | 183 |
| NGPs 7 | Scfm | 8.4 | 7.7 | 6.9 | 6 | 4.7 | 3.6 | 2.5 | 2.2 | 1.4 | 1.3 | 0.9 | 17 | 18 | 59 | 212 |
| NGPs 9 | Scfm | 11.1 | 10.1 | 8.3 | 7.2 | 5.8 | 4.7 | 3.2 | 2.8 | 2 | 1.8 | 1.1 | 17 | 18 | 73 | 249 |
Options: Advanced controller, Nitrogen check, Feed air check, Nitrogen PDP sensor, Nitrogen flow sensor, Mass flow control valve, Room oxygen alarm (wall mount)
