Nano GEN2 Mini Series Nitrogen Generators
Low-Capacity Nitrogen Generators
Looking for a dependable, cost-effective, and safe source of high-purity nitrogen for your low-flow applications? Look no further than nano’s GEN2 MINI PSA nitrogen gas generator. It produces a continuous and clean supply of nitrogen gas with a purity level of 95% to 99.999% from compressed air, eliminating the need for costly and hazardous nitrogen transportation. With advanced controls and lower air consumption, it is an innovative and energy-efficient way to produce nitrogen on-site. Choose nano’s GEN2 MINI PSA nitrogen gas generator for your small flow applications and enjoy a reliable and cost-effective source of high-purity nitrogen at your fingertips.
| Nitrogen Generator Model |
Rated Outlet Flow at 101.5 psig |
Nitrogen Gas Purity at the Outlet (Maximum Oxygen Content) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 99.999% (10 ppm) |
99.995% (50 ppm) |
99.99% (100 ppm) |
99.95% (500 ppm) |
99.9% (0.10%) |
99.5% (0.50%) |
99% (1%) |
98% (2%) |
97% (3%) |
95% (5%) |
||
| GEN2MINI-060 | scfh | – | – | – | 21 | 28 | 60 | 74 | 99 | 120 | 152 |
| GEN2MINI-080 | scfh | – | 28 | 35 | 46 | 60 | 99 | 131 | 166 | 194 | 244 |
| GEN2MINI-100 | scfh | 18 | 46 | 53 | 78 | 88 | 148 | 187 | 240 | 276 | 339 |
| GEN2MINI-110 | scfh | 28 | 49 | 60 | 95 | 113 | 184 | 226 | 276 | 311 | 392 |
| GEN2MINI-120 | scfh | 57 | 78 | 88 | 131 | 152 | 219 | 283 | 357 | 413 | 505 |
| GEN2MINI-130 | scfh | 64 | 106 | 120 | 166 | 194 | 279 | 350 | 431 | 498 | 664 |
- Ultra compact design and wide range of flow rates, make it the perfect generator for a variety of lower flow nitrogen applications.
- Significant cost savings over cylinder or liquid supply provides a typical return on investment of less than 24 months.
- Uses pressure swing adsorption to produce a continuous, uninterrupted supply of 95 to 99.999% purity nitrogen gas from clean, dry compressed air.
- 100% functional tested with 2 year warranty.
- Eliminates safety concerns associated with transporting and storing pressurized gas cylinders or liquid nitrogen.
- Reduces carbon footprint by eliminating gas delivery with positive impacts on sustainability targets.
- eco-mode energy savings control reduces energy consumption during periods of low demand.
- Optional integrated O2 analyzer and dew point sensors (N2 or inlet air)
